| Part Number | 51412 |
| Bearing type | BALL |
| Structure | THRUST BALL |
| Load Direction | AXIAL |
| Raceway type | groove raceway |
| bore diemater of shaft washer(d) | 60mm |
| Outer diameter of housing washer(D) | 130mm |
| bore diemater of housing washer(d1) | 62mm |
| Outer diameter of shaft washer(D1) | 130mm |
| thickness( H) | 51mm |
| radius | 1.5mm |
| material of washers | Chrome steel 52100(Gcr15) |
| material of cage | bronze or stainless steel |
| ball material | Chrome steel 52100(Gcr15) |
| Grade | ABEC-1(higher grade available) |
| Clearance | C0(other clearance available) |
| BALL SIZE(mm) | |
| BALL QTY | |
| lubrication | grease(oil available) |
| Temperature Range | -30℃~130℃ |
| weight(g) | 3080 |
| ISO9001:2015 | PASSED |
| REACH | PASSED |
| ROHS | PASSED |
| Dynamic Load Rating (Cr) | 200 KN |
| Static Load Rating (Cor) | 395 KN |
| Limit speed(rpm)for bearing with grease | 1000 |
| Limit speed(rpm)for bearing with oil | 1600 |
friendly reminder
The unit weight is 3.08 KG per piece,so please consider the suitable way of delivery before order.
BEARING INTERCHANGE
| RUNSTAR | NMB | NTN | ADR | GRW | EZO | TIMKEN |
| 51412 |
