Part Number | SMR126ZZ |
Bearing type | BALL |
Structure | Single Row |
Load Direction | Radial |
Seal type | Shields |
Bore diameter(d) | 6mm |
Outer diameter(D) | 10mm |
Width(B) | 4 mm |
material | Stainless steel 440C(9Cr18) |
ring material | Stainless steel 440C(9Cr18) |
cage material | Stainless steel 304 |
ball material | Stainless steel 440C(9Cr18) |
Rubber material | Stainless steel 304 with rubber |
Grade | ABEC-1 |
Clearance | C0 |
BALL SIZE(mm) | 1.588mm |
BALL QTY | 8 |
lubrication | grease or oil |
Temperature Range | -30℃~130℃ |
weight(g) | 1.66 |
ISO9001:2015 | PASSED |
REACH | PASSED |
ROHS | PASSED |
Dynamic Load Rating (Cr) | 609N |
Static Load Rating (Cor) | 236 N |
Stainless Bearings are also called stainless steel ball bearings or stainless steel bearings. Compared with ordinary ball bearing with chrome steel, Stainless bearings can keep from corrosion caused by some acids or moisture,and stainless steel bearings have obvious advantages of stable operation, low noise, low magnet, wide application, excellent anti-corrosion and anti-rust properties.
The item SMR126ZZ is a very pop in industries, it is a metric stainless bearings with shields, with a bore diameter 6mm,a outer diameter 12mm and a width 4mm,and it can support the dynamic load rating 716 N. It can be widely uded in fishing reel,home applicance and food processing machinery etcs.
Established in 2007, Runstar is a professional stainless bearings manufacturer in China,certified ISO9001:2015. we design and make stainless bearings with a grade from ABEC-1 to ABEC-9, stainless bearings with hybrid ceramic balls are available in Runstar. All stainless bearings from Runstar are strictly controlled under ISO9001:2015,with RoHs and REACH compliance.
BEARING INTERCHANGE
RUNSTAR | NMB | NTN | ADR | GRW | EZO | TIMKEN |
SMR126zz | SL-1260zz | SX6zz | SMR126zz |
