Part Number | 681XZZ |
Bearing type | BALL |
Structure | Single Row |
Load Direction | Radial |
Seal type | open |
Bore diameter(d) | 1.5mm |
Outer diameter(D) | 4mm |
Width(B) | 2mm |
material | Chrome steel 52100(Gcr15) |
ring material | Chrome steel 52100(Gcr15) |
cage material | 300 Series Stainless Steel |
ball material | Chrome steel 52100(Gcr15) |
shields material | 300 Series Stainless Steel |
Grade | ABEC-1 |
Clearance | C0 |
BALL SIZE(mm) | 0.6mm |
BALL QTY | 7 |
lubrication | grease or oil |
Temperature Range | -30℃~130℃ |
weight(g) | 0.14 |
ISO9001:2015 | PASSED |
REACH | PASSED |
ROHS | PASSED |
Dynamic Load Rating (Cr) | 95 N |
Static Load Rating (Cor) | 26 N |
![rc bearing 681xzz d rc bearing 681xzz d](https://www.runstarbearing.com/wp-content/uploads/2020/11/rc-bearing-681xzz-d.jpg?v=1606200805)
BEARING INTERCHANGE
RUNSTAR | NMB | NTN | ADR | GRW | EZO | TIMKEN |
681XZZ | L-415ZZ | W68/1.5ZZA | X1.5ZZ | 68/1.5-2Z | 681XZZ |
