| Part Number | SR09 |
| Bearing type | BALL |
| Structure | Single Row |
| Load Direction | Radial |
| Seal type | Open |
| Bore diameter(d) | 1/25″︱1.016mm |
| Outer diameter(D) | 1/8″︱3.175mm |
| Width(B) | 3/64″︱1.191mm |
| material | Stainless steel 440C(9Cr18) |
| ring material | Stainless steel 440C(9Cr18) |
| cage material | Stainless steel 304 |
| ball material | Stainless steel 440C(9Cr18) |
| Rubber material | Stainless steel 304 with rubber |
| Grade | ABEC-1 |
| Clearance | C0 |
| BALL SIZE(mm) | 0.635mm |
| BALL QTY | 6 |
| lubrication | grease or oil |
| Temperature Range | -30℃~130℃ |
| weight(g) | 0.05 |
| ISO9001:2015 | PASSED |
| REACH | PASSED |
| ROHS | PASSED |
| Dynamic Load Rating (Cr) | 88 N |
| Static Load Rating (Cor) | 22 N |
Precision miniature radial ball bearings is also called precision miniature bearings in Runstar,it is referred to miniature ball bearings with high precision.Runstar is a professional precision miniature bearings manufacturer in China, certified ISO9001:2015. We supply precision miniature bearings from ABEC-1 to ABEC-9 for applications,the material could be chrome steel,stainless steel or hybrid ceramic for choice. Most of precision miniature bearings from Runstar are widely used in precision instrument,home application,medical device,massage equipment,sports equipment,textile machinery,woodworking machinery,motor,power tool,water pump,air compressor,fishing reel and Yoyo etcs.
BEARING INTERCHANGE
| RUNSTAR | NMB | NTN | ADR | GRW | EZO | TIMKEN |
| SR09 | SR1-2 | SR01 | SR09 | S1016 | SR09 |
