| Part Number |
F3-8M |
| Bearing type |
BALL |
| Structure |
THRUST BALL |
| Load Direction |
AXIAL |
| Raceway type |
groove raceway |
| bore diemater of shaft washer(d) |
3mm |
| Outer diameter of housing washer(D) |
8mm |
| bore diemater of housing washer(d1) |
3.2mm |
| Outer diameter of shaft washer(D1) |
7.8mm |
| thickness( H) |
3.5 mm |
| radius |
0.15mm |
| material of washers |
Chrome steel 52100(Gcr15) |
| material of cage |
bronze or stainless steel |
| ball material |
Chrome steel 52100(Gcr15) |
| Grade |
ABEC-1(higher grade available) |
| Clearance |
C0(other clearance available) |
| BALL SIZE(mm) |
1.588 mm |
| BALL QTY |
7 |
| lubrication |
grease(oil available) |
| Temperature Range |
-30℃~130℃ |
| weight(g) |
0.6 |
| ISO9001:2015 |
PASSED |
| REACH |
PASSED |
| ROHS |
PASSED |
| Dynamic Load Rating (Cr) |
933 N |
| Static Load Rating (Cor) |
590 N |
|
|
|
|
