Part Number | SR6 |
Bearing type | Ball |
Structure | Single Row |
Load Direction | Radial |
Seal type | Open |
Bore diameter(d) | 3/8″︱9.525mm |
Outer diameter(D) | 7/8″︱22.225mm |
Width(B) | 0.2188″︱5.558mm |
material | Stainless steel 440C(9Cr18) |
ring material | Stainless steel 440C(9Cr18) |
cage material | Stainless steel 304 |
ball material | Stainless steel 440C(9Cr18) |
Rubber material | Stainless steel 304 with rubber |
Grade | ABEC-1 |
Clearance | C0 |
BALL SIZE(mm) | 3.97mm |
BALL QTY | 7 |
lubrication | grease or oil |
Temperature Range | -30℃~130℃ |
weight(g) | 9.02 |
ISO9001:2015 | PASSED |
REACH | PASSED |
ROHS | PASSED |
Dynamic Load Rating (Cr) | 2834 N |
Static Load Rating (Cor) | 1139 N |
BEARING INTERCHANGE
RUNSTAR | NMB | NTN | ADR | GRW | EZO | TIMKEN |
SR6 | SRI-1438 | SR6 | SY3/8 | SBR3/8 | SR6 |
