| Part Number | F6700-2RS |
| Bearing type | BALL |
| Structure | Single Row |
| Load Direction | Radial |
| Seal type | Rubber seals |
| Bore diameter(d) | 10 mm |
| Outer diameter(D) | 15mm |
| Flange OD(Df) | 16.5 mm |
| Width(B) | 4 mm |
| Flange thickness (Bf) | 0.8mm |
| radius (rs) | 0.15mm |
| material | Chrome steel 52100(Gcr15) |
| ring material | Chrome steel 52100(Gcr15) |
| cage material | 300 Series Stainless Steel |
| ball material | Chrome steel 52100(Gcr15) |
| shields material | 300 Series Stainless Steel |
| Grade | ABEC-1(higher grade available) |
| Clearance | C0(other clearance available) |
| BALL SIZE(mm) | 1.588mm |
| BALL QTY | 11 |
| lubrication | grease(oil available) |
| Temperature Range | -30℃~130℃ |
| weight(g) | 2 |
| ISO9001:2015 | PASSED |
| REACH | PASSED |
| ROHS | PASSED |
| Dynamic Load Rating (Cr) | 855N |
| Static Load Rating (Cor) | 435 N |
10mm Flange Bearing is referred to flange bearings or miniature flange bearings with a inner diameter 10mm.
F6700-2RS is one of 10mm Flange Bearing,it is with a inner diameter 10mm,a outer diameter 15mm and a width 4mm,and it is a flange bearins with rubber seals.
The 10mm flange bearings are made of chrome steel or stainless steel, as well as hybrid ceramic for choice, from ABEC-1 to ABEC-7.
Founded in 2007, Zhangzhou Runstar Bearings Manufacturing Co ltd is a professional manufacturer of miniature ball bearings ,certified ISO9001:2015, we have been committed to the design and production of 10mm Flange Bearing with high precision and high speed, who has more than 15 year’s experience in designing and manufacturing 10mm Flange Bearing for industries.
BEARING INTERCHANGE
| RUNSTAR | NMB | NTN | ADR | GRW | EZO | TIMKEN |
| F6700-2RS |
